Collection: MCP70

The EMCO Famup MCP70-50 is a vertical machining center with pallet changer, equipped with a Fanuc 18 CNC control. Travels are 700 mm along the X-axis, 500 mm along the Y-axis, and 640 mm along the Z-axis. It is equipped with two work tables (600 x 450 mm) that enable efficient machining. The machine has a spindle speed of 12,000 rpm and a spindle power of 22.5 kW (35 kW in S6 mode). The continuous torque is 76 Nm, or 120 Nm in S6 mode. The tool magazine has space for 30 tools in ISO 40 format. The high-speed travel is 40 m/min, and it is equipped with high-pressure cooling for the spindle. The machine was built in 2007 and measures 3915 x 3608 x 3640 mm.

.

.
